Flat Bar Steel for Ship Building

type	size(mm)			CSA (cm2)	weight(kg/m)	allowable deviation (mm)
type	b	t	r	CSA (cm2)	weight(kg/m)	b	t
8×100 10×100 12×100 15×100	100	8	≤2.0	8.0	6.28	± 2.0	± 0.3
		10		10.0	7.85
		12		12.0	9.42
		15	≤3.0	15.0	11.78
8×120 10×120 15×120	120	8	≤2.0	9.6	7.54
		10	≤2.0	12.0	9.42
		15	≤3.0	15.0	14.13
10×150 12×150 15×150 20×150 25×150 30×150	150	10	≤2.0	15.0	11.78
		12	≤2.0	18.0	14.13
		15	≤3.0	22.5	14.13
		20	≤3.0	30.0	23.55
		25	≤4.0	37.5	29.44
		30	≤4.0	45.0	35.33
10×200 10×200 10×200 10×200 10×200 10×200	200	10	≤2.0	20.0	15.70	± 0.3	± 0.3
		12	≤2.0	24.0	18.84
		15	≤3.0	30.0	23.55
		20	≤3.0	40.0	31.40
		25	≤4.0	50.0	39.25
		30	≤4.0	60.0	47.10
10×250 12×250 15×250 20×250 25×250 30×250	250	10	≤2.0	25.0	19.63
		12	≤2.0	30.0	23.55
		15	≤3.0	37.0	29.44
		20	≤3.0	50.0	39.25
		25	≤4.0	62.0	49.06
		30	≤4.0	75.0	58.88
10×300 12×300 15×300 20×300 25×300 30×300	300	10	≤2.0	30.0	23.55
		12	≤2.0	36.0	28.26
		15	≤3.0	45.0	35.33
		20	≤3.0	60.0	47.10
		25	≤4.0	75.0	58.88
		30	≤4.0	90.0	70.65
10×350 12×350 15×350 20×350 25×350 30×350	350	10	≤2.0	35.0	27.48	± 0.4	± 0.3
		12	≤2.0	42.0	32.97
		15	≤3.0	52.5	41.21
		20	≤3.0	70.0	54.95
		25	≤4.0	87.5	68.69
		30	≤4.0	105.0	82.43
10×400 12×400 15×400 20×400 25×400 30×400	400	10	≤2.0	40.0	31.40
		12	≤2.0	48.0	37.68
		15	≤3.0	60.0	47.10
		20	≤3.0	80.0	62.80
		25	≤4.0	100.0	78.50
		30	≤4.0	120.0	94.20
10×450 12×450 15×450 20×450 25×450 30×450	450	10	≤2.0	45.0	35.33
		12	≤2.0	54.0	42.39
		15	≤3.0	67.5	52.99
		20	≤3.0	90.0	70.65
		25	≤4.0	112.5	88.31
		30	≤4.0	135.0	105.98
