NAXTRA 70 Plates
Champak Industries' is a specialist supplier and exporter of High strength steels NAXTRA 70 Plates. We understand customers whose requirement for High strength steels Plates is extreme and who cannot use inferior quality steel plates.
STOCKIST OF HIGH YIELD STRUCTURAL STEEL PLATES
| HIGH YIELD STRUCTURAL STEEL PLATES | ||||||||
| Steel Grade | ||||||||
| Finland | Germany | Japan | Germany | Sweden | Austria | Belgium | ||
| S690QL | DILLIMAX 690T |
JFE HITEN 780 LE |
NAXTRA 70 |
WELDOX 700 |
ALFORM 700 |
1.8928 | ||
HIGH YIELD STRUCTURAL STEEL PLATES
NAXTRA 70 Plates is a high yield structural steel or High strength steels grade produced in compliance with EN 10025:6:2004. The material is heats treated using the quench and temper process and has good bending and welding properties
The code "S" for steel grade S690QL means structural steel.
The code "Q"refers to the delivery condition, in this case to quenched & Tempered.
The code "L" means that the average minimum values for impact energy have been defined at a temperature of -40°C.
Due to the materials high strength nature, using S690QL will promote leaner designed structures with increased payload capacity and energy efficiency.
The code "S" for steel grade S690QL means structural steel.
The code "Q"refers to the delivery condition, in this case to quenched & Tempered.
The code "L" means that the average minimum values for impact energy have been defined at a temperature of -40°C.
Due to the materials high strength nature, using S690QL will promote leaner designed structures with increased payload capacity and energy efficiency.
The steel is used in a variety of Segments including
- Machine building
- Lifting equipment
- Heavy transportation
- Steel constructions
APPLICATIONS:
- Crane booms
- Mining and earthmoving equipment
- Bridges
- Material handling
- Trailers and agricultural equipment.
CHEMICAL COMPOSITION
| Grade | C | Si | Mn | P | S | N | B | Cr | Cu | Mo | Nb* | Ni | Ti* | V* | Zr* |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S690 QL | 0.20 | 0.80 | 1.70 | 0.025 | 0.015 | 0.015 | 0.0050 | 1.50 | 0.50 | 0.70 | 0.06 | 2.0 | 0.05 | 0.12 | 0.15 |
At least 0.015% of grain-refining element present. Aluminium is also one of these elements.
MECHANICAL PROPERTIES
| Tensile Strength (MPa) | Yield Strength (MPa)) | Min. % Elongation after fracture | ||||
| Nominal thickness (mm) | Nominal thickness (mm) | |||||
| =3 =50 | =50 =100 | =100 =150 | =3 =50 | =50 =100 | =100 =150 | |
| 690 | 690 | 690 | 770 - 940 | 770 - 940 | 770 - 940 | 14 |
V NOTCH IMPACT TESTING
| Grade | Sample Orientation | @ 0ºC | @-20ºC | @-40ºC | @-60ºC |
| S690QL | Longitudinal | 50 J | 40 J | 30 J | –– |
| Traverse | 35 J | 30 J | 27 J | –– |
