2124 Aluminium Plates
Alloy 2124 aluminum plates are a high purity form of 2024 and are normally supplied in 1.50" - 6.00" plate. Available in T851 temper, this plate alloy exhibits good strength retention and creep resistance at elevated temperatures up to 350 degrees. Fracture toughness levels of 2124-T851 plate are significantly higher than 2024-T851. This alloy is recommended for those applications requiring better short-transverse ductility, high strength and good machinability and has excellent exfoliation corrosion resistance. Fatigue properties of alloy 2124-T851 are similar to those of 2024-T851.
Applications
• Machined fuselage bulkheads
• Wing skins in high-performance military aircraft
• Wing skins in high-performance military aircraft
Technical Data Sheet
| Silicon | 0.20 |
| Iron | 0.30 |
| Copper | 3.8-4.9 |
| Manganese | 030.-0.9 |
| Magnesium | 1.2-1.8 |
| Chromium | 0.10 |
| Zinc | 0.25 |
| Titanium | 0.15 |
| Others, each | 0.05 |
| Others, total | 0.15 |
| Balance, Aluminum |
Typical Mechanical Properties
| Thickness | Tensile Strength | Yield Strength | Elongation |
|---|---|---|---|
| In. | KSI | KSI | % |
| 1.001-2.00 | 66 | 57 | 5 |
| 5.001-6.00 | 63 | 54 | 4 |
