5754 Aluminium Plates
We have huge stock of 5754 aluminium/ Aluminum plates. Aluminium 5754 has excellent corrosion resistance especially to seawater and industrially polluted atmospheres and it has high weldability . It has higher strength than 5251. This high strength makes 5754 highly suited to flooring applications.
Applications
. Treadplate
. Shipbuilding
. Vehicle bodies
. Rivets
. Fishing industry equipment
. Food processing
. Welded chemical and nuclear structures
. Shipbuilding
. Vehicle bodies
. Rivets
. Fishing industry equipment
. Food processing
. Welded chemical and nuclear structures
Chemical Composition
| Chemical Element | % Present |
|---|---|
| Manganese (Mn) | 0.0 - 0.50 |
| Iron (Fe) | 0.0 - 0.40 |
| Magnesium (Mg) | 2.60 - 3.60 |
| Silicon (Si) | 0.0 - 0.40 |
| Chromium (Cr) | 0.0 - 0.30 |
| Copper (Cu) | 0.0 - 0.10 |
| Manganese + Chromium (Mn+Cr) | 0.10 - 0.60 |
| Other (Each) | 0.0 - 0.05 |
| Others (Total) | 0.0 - 0.15 |
| Titanium (Ti) | 0.0 - 0.15 |
| Zinc (Zn) | 0.0 - 0.20 |
| Aluminium (Al) | Balance |
Physical Properties
| Physical Property | Value |
|---|---|
| Density | 2.66 g/cm³ |
| Melting Point | 600 °C |
| Thermal Expansion | 24 x10^-6 /K |
| Modulus of Elasticity | 68 GPa |
| Thermal Conductivity | 147 W/m.K |
| Electrical Resistivity | 0.049 x10^-6 Ω .m |
| Spec: BS EN 485-2:2008 | Sheet & Plate - 0.2mm to 40mm |
|---|---|
| Mechanical Property | Value |
| Proof Stress | 130 Min MPa |
| Tensile Strength | 220 - 270 MPa |
| Hardness Brinell | 63 HB |
| Elongation A50 mm | 7 Min % |
