3003 Aluminium Plates
Champak Industries is leading supplier of 3003 aluminium Plates and this 3003 aluminum plates react well to mechanical finishing and organic finishes as well. 3003 welding is readily accomplished by means of conventional welding methods but may be gummy if machined. Soldering is limited to the torch method. 3003 plate is generally used for manufactured stamped parts because of its light weight and moderate strength. TW has a wide range of sizes readily available to the AMS 4008 for H14.
Applications
• Cat Walks
• Heat Exchangers
• Food and Chemical handling equipment
• Truck and Trailer Roofing
• Floor Panels
• Heat Exchangers
• Food and Chemical handling equipment
• Truck and Trailer Roofing
• Floor Panels
Chemical Composition
| Chemical Element | % Present |
|---|---|
| Others (Total) | 0.0 - 0.15 |
| Cobalt (Co) | 0.05 - 0.20 |
| Hydrogen (H) | 0.0 - 0.70 |
| Magnesium (Mg) | 1.00 - 1.50 |
| Silicon + Iron (Si+Fe) | 0.0 - 0.60 |
| Zirconium (Zr) | 0.0 - 0.10 |
| Other (Each) | 0.0 - 0.05 |
| Aluminium (Al) | Balance |
Properties
| Physical Property | Value |
|---|---|
| Density | 2.73 g/cm³ |
| Melting Point | 655 °C |
| Thermal Expansion | 23.1 x10^-6 /K |
| Modulus of Elasticity | 69.5 GPa |
| Thermal Conductivity | 190 W/m.K |
| Electrical Resistivity | 0.034 x10^-6 Ω .m |
| Spec: BS EN 485-2:2008 | Sheet - 0.2mm to 6.00mm |
|---|---|
| Mechanical Property | Value |
| Tensile Strength | 95 - 135 MPa |
| Proof Stress | 35 Min MPa |
| Hardness Brinell | 28 HB |
