Our Product Range

the leading stockiest, importers, exporters & suppliers of AR Plates

AR Plates



AR is a very wear-resistant sheet steel. AR is imported and exported worldwide by the Champak Industries. As this steel wears slowly, even under huge mechanical loads, AR is also called wear plate. this fact is mainly interesting for companies that quarry gravel and sand as, for example, excavator buckets or unload truck our bodies made from hardox ultimate rapid longer.

This material is characterised by its uniform evenness, high hardness and high strength. The weight of the constructions produced is reduced significantly. This is possible, because the material's high strength enables thinner steel sheets to be used. AR does not lose its impact resistance, even at low temperatures. As these sheets and plates have very good welding and machining properties, subsequent repairs of wearing parts is not a problem.

By choosing Wear plates with higher hardness levels it is possible to reduce the weight of a construction by up to 15 %. An increase by 50 Brinell extends the life of the work piece by 50 to 80 percent.

AR plates Hardening (quenching) and tempering sheets and plates produces the outstanding properties, which can be lost if worked incorrectly. Therefore precautions and protective measures must be taken when bending, welding, cutting and grinding.

AR Flexibility – Bending and Folding

AR plates or wear plates with high strengths can be cold worked by bending and roll bending. Due to the higher strength, however, factors must be applied to ensure that the bending and roll bending can be carried out with the best possible quality.

Rules for Bending and folding
• The bending forces to be applied increases with the increasing strength of the material.
• Metal sheet and plate with higher strength springs back during bending more than normal steel sheets and plates.
• The harder and stronger the metal sheet or plate is, the larger the punch radius and die width that have to be chosen.

Metal Plates surface

Defects and rust deposits can reduce flexibility. Therefore, before bending and folding AR such defects must be ground off. During the bending process the machine operator should stand to the side of the press brake, as the high forces that act on the high-strength steel plate can cause cracks in the surface and parts of the work piece surface can shoot off in the bending direction.

The measures are recommended to avoid vibrations and damage
• small distance between the drill bit and machine pillar
• clamp the work piece securely
• do not insert any wood under the work piece
• Use short drill bits and machine spindles, in order to minimize the distance between the tip of the drill and the cantilever arm
• Relax the drill just before penetrating the material, by switching off the feed briefly. This protects the drill against damage.
• Use plenty of cooling liquid (cooling liquid [l/min] ~ drill bit diameter [mm]

A comparison of different AR grades

AR 400
• Sheet thickness 3 – 130 mm
• Brinell hardness 370 – 430

AR 450
• Sheet thickness 3 – 80 mm
• Brinell hardness 425 – 475

These are used if a combination of high wear resistance and good cold working properties is required. These sheets and plates are used, for example, to produce dumper trucks, screens, chutes, rock crushing machines, excavators and conveyors. These steel grades are characterised by their very good weld ability.

AR 500
• Sheet thickness 4 – 32 mm
• Brinell hardness 470 – 530
• Sheet thickness 32 – 80 mm
• Brinell hardness 370 – 430

AR 550
• Sheet thickness 10 – 50 mm
• Brinell hardness 525 – 575

These are used if high requirements are necessary with regard to wear resistance. These sheets and plates are used, for example, to make conveyors, blades and cutters, buckets for excavators, gear wheels and crushing plants.

The material must not be heated above 250°C, as otherwise the sheet or plate can lose its outstanding properties.

AR 600
• Sheet thickness 8 – 50 mm
• Brinell hardness 560 – 640

This is used if high requirements are necessary with regard to wear resistance. This sheet / plate is used, for example, to make chutes, crushers, hammers and shredders.

AR HiTuf
• Sheet thickness 40 – 120 mm
• Brinell hardness 310 – 370

This is used if extremely high requirements are necessary with regard to toughness (ductility) and wear resistance. It is used to make, for example, demolition tools and cutting edges.

AR Extreme
• Sheet thickness 10 mm
• Brinell hardness 700
• Sheet thickness 25 mm
• Brinell hardness 650

This is used if extremely high requirements are necessary with regard to wear resistance.
This sheet / plate is used, for example, to make hammers, crushers, wear protection plate (armour plate) cutting equipment.
Use plenty of cooling liquid (cooling liquid [l/min] ~ drill bit diameter [mm]

Today this steel is available in the grades: AR 400 / 450 / 500 / 550 / 600 / HiTuf or even Extreme. These differ with regard to their hardness, toughness, flexibility and the possibility of welding.
