the leading stockiest, importers, exporters & suppliers of Nicrodur 450 Plates

Nicrodur 450 Plates



Champak Industries' is a specialist supplier and exporter of thick NICRODUR 450 Plates and NICRODUR 500 Plates wear resistant steel plates. We understand customers whose requirement for wear resistant steel plate is extreme and who cannot use thinner abrasion resistant plates.

This NICRODUR Wear resistant heavy plate NICRODUR is a wear resistant heavy plate with hardness from 360 to 540 HBW. The unique combination of high hardness, high strength and good toughness makes this material well suited for a wide variety of applications in which it is exposed to heavy wear by hard minerals and other abrasive materials. NICRODUR is characterized by its very good weldability, formability and machining properties. The range of NICRODUR products are NICRODUR 400, NICRODUR 450 and NICRODUR 500.

WNr Stahl eisen liste Acroni
1.8715 17MnCr 5 – 3 NICRODUR 400
1.8720 18MnCr5-3 NICRODUR 450
1.8721 26MnCr6-3 NICRODUR 500

Chemical Composition

Plate Thickness [mm] C max Si max Mn max S max P max Cr max Ni max Mo max B max CEV max
NICRODUR 400
8 - 20 0,16 1,0 1,5 0,002 0,012 0,8 0,5 0,5 0,004 0,45
(20) - 40 0,18 1,0 1,5 0,002 0,012 0,9 0,5 0,5 0,004 0,56
(40) - 80 0,23 1,0 1,5 0,002 0,012 1,1 0,5 0,5 0,004 0,65
NICRODUR 450
8 - 20 0,18 1,0 1,5 0,002 0,012 0,8 0,5 0,5 0,004 0,47
(20) - 40 0,19 1,0 1,5 0,002 0,012 0,9 0,5 0,5 0,004 0,56
(40) - 60 0,23 1,0 1,5 0,002 0,012 1,1 0,5 0,5 0,004 0,65
(60) - 80 0,25 1,0 1,5 0,002 0,012 1,1 0,5 0,5 0,004 0,71
NICRODUR 500
8 - 25 0,28 1,0 1,5 0,002 0,012 1,0 0,5 0,5 0,005 0,61
(20) - 40 0,32 1,0 1,5 0,002 0,012 1,1 0,5 0,5 0,005 0,71
(40) - 60 0,34 1,0 1,5 0,002 0,012 1,2 0,7 0,5 0,005 0,76
(60) - 80 0,40 1,0 1,5 0,002 0,012 1,5 1,0 0,5 0,005 0,81

Hardness HBW

NICRODUR 400 NICRODUR 450 NICRODUR 500
360 - 440 420 - 477 460 - 540

Mechanical Properties

Yield strength(minimal), Re [MPa] Tensile strength, Rm [MPa] Elongation (minimal), A5 [%]
NICRODUR 400 1200 1380 9
NICRODUR 450 1280 1450 9
NICRODUR 500 1500 1800 9
Typical values for 15 mm plate thickness

Impact Properties

Test temperature Impact energy Charpy – V, transverse
[°C] [J]
-40 30
Typical values for 15 mm plate thickness

Bending

Thickness Transverse Longitudinal Transverse Longitudinal Springback
NICRODUR 400 8 ≥ t < 20
t ≥ 20
3,0
4,5
4,0
5,0
10,0
12,0
10,0
12,0
9 - 13
NICRODUR 450 8 ≥ t < 20
t ≥ 20
4,0
5,0
5,0
6,0
10,0
12,0
12,0
14,0
11 - 18
NICRODUR 500 8 ≥ t < 20
t ≥ 20
5,0
7,0
6,0
8,0
12,0
16,0
14,0
18,0
12 - 20
Minimum recommended punch radius (R) and die opening width (W) for plate thickness (t) when the plate is being bent to 90° along the direction of rolling and at right angles to the direction of rolling – and also the corresponding springback.

Maximum recommended preheat temperature

  8 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80
NICRODUR 400 room 75 100 175
NICRODUR 450 room 125 150
NICRODUR 500 room 175 200
* for thicknesses up to 13mm | Data from the table is applicable to single plate thickness when welding with a heat input of 1.7kJ/mm. | The consumables determine the preheating temperature if its carbon equivalent is higher than of the plate | Room temperature is approx 20°C

Maximum recommended interpass temperature

NICRODUR 400 225
NICRODUR 450 225
NICRODUR 500 225
