JFE EH 400 (JFE, Japan Make)
JFE Steel Co. pioneered the production and sale of abrasionresistant steel plate in Japan in the mid-1950s, and
JFE abrasion-resistant steel plate (JFE EVERHARD) enjoyed widespread use as a vital material for construction, mining, civil engineering and farming equipment.
Furthermore, JFE Steel Co. has succeeded in developing super abrasion-resistant steel plate EH-SP with higher abrasionresistance than that of the Brinell 500 grade, and EH360LE,
EH400LE, EH500LE with excellent toughness through the leading edge of production technology. Those products enjoy customer's reputation.
In this catalog, we would like to introduce the JFE EVERHARD series of abrasion-resistant steel plate.
In this catalog, we would like to introduce the JFE EVERHARD series of abrasion-resistant steel plate.
A variety of available grades
A total of 9 grades are available ; the standard series
and the alloy series with 3 and 2 grades of hardness
respectively, a new super abrasion resistant grade,
as well as 360 grade, 400 grade and 500 grade with
high toughness, providing a complete product line
that can meet a wide range of applications.
Standard Series
This series consists of grades produced with the
main emphasis on their hardness levels, the chemical
composition being basically simple with boron
added while the additon of other alloying elements
is restrained.
Alloy Series
This series contains alloying elements in greater
quantities than the standard series. The prescribed
hardness is guaranteed for plate thickness of up to
100mm and, at the same time, carefull consideration
has been given to low-temperature toughness.
Super Abrasion resistant plate EH-SP
Customers often call for the development of a
longer-lasting abrasion-resistant plate in order to
reduce running cost. However up to now, it has been
difficult to develop an abrasion resistant plate that
performs better than the conventional 500 grade
plate, without reducing the plate's weldability and
formability.
Our new higher abrasion resistant plate succeeds in
doing this.
Abrasion- resistant steel plate wi th excellent toughness EH360LE, EH400LE, EH500LE
High toughness at -40˚C of abrasion-resistant steel
plate was generally difficult to be guaranteed.
JFE has succeeded in developing abrasionresistant
steel plate including 500 grade with
excellent toughness guaranteed at -40˚C. EH360LE,
EH400LE and EH500LE are the most suitable plates
when high toughness is required because of the
application in low temperature environment and/or
suffering with high impact.
EH360LE has also high resistance to weld cracking,
then presents high quality and safety of welded
joint.
Superb quality
JFE's abrasion-resistant steel plates are produced at
modern Works. Based on many years of experience,
production incorporates the latest in heat treatment
technology and proceeds under strict quality control.
The result is high-quality steel plate that offers
not only outstanding abrasion-resistance but good
weldability and workability as well.
JFE EVERHARD is manufactured for non-structural steel plates which are specified by chemical analysis of molten steel, Brinell hardness at the plate surface and material toughness. It is not specified and guaranteed by its tensile strength and elongation which are required to be specified as structural steel plates. In case of any request for the tensile strength and/or elongation as reference, please refer to JFE Steel Technical Bulletins.
JFE EVERHARD is manufactured for non-structural steel plates which are specified by chemical analysis of molten steel, Brinell hardness at the plate surface and material toughness. It is not specified and guaranteed by its tensile strength and elongation which are required to be specified as structural steel plates. In case of any request for the tensile strength and/or elongation as reference, please refer to JFE Steel Technical Bulletins.
